Threshold relay 8A
Threshold relays convert the analogue signal into the signal controlling the relay output. Therefore, sensors with an analogue output can be used in automation systems.
Relays continuously measure the voltage (PA-01U) or current (PA-01I ) signal connected to the input terminals.
These models can operate in four different modes selected (FUNC button).
Technical characteristics:
- Supply voltage: 9-30V DC
- Maximum load current: 8A
- Contacts: 1 x NO/NC
- Maximum consumption: 100 mA
