Gear unit TKB38B

Gear unit 2 stages / Output hollow shaft Ø25 mm
Torque from 23 to 200 N.m
Output speed from 14.9 to 368 RPM

Speed-reduction gear ratio

Reference RED_TKB38B_007

Last items in stock

€225.78 -5%
€214.49 Excl. tax

Gear unit TKB38 2 and 3 stages:
The hypoid gear* transmission ratio offer an excellent efficiency in transmission
and in energy savings, far greater than traditional worm gears (2).
Output torque: 23 to 200 N.m
Output speed: 14.9 to 368 RPM

Advantages:

More silent than helical gears
Compact structure and small size
Light weight thanks to its aluminium alloy

(1) η=94%

Image d'un réducteur 2 étages / Sortie arbre creux Ø25 mm

Areas of application:

Machine tool: press, press brake, trimmer, cutting
Conveyor, bottling, food industry, pharmaceutical, textile, paper, ...

*Output hollow shaft Ø25 mm

Max torque 200Nm

* Hypoid gears are halfway between worm drives and bevel gears. (1)

(2) η=62%

Image d'un réducteur 2 étages / Sortie arbre creux Ø28 mm
