Worm gear unit TNRV 050

Worm gear unit torque from 17 to 89 N.m
Hollow shaft output Ø25 mm
Output speed from 11 to 368 RPM

Select your gear unit TNRV50

Reference RED_TNRV50_007

Pre-order

€118.66 -5%
€112.73 Excl. tax

Worm gear unit TNRV50:
Colour: blue or silver

Advantages:

Softer and more silent than helical gears
Compact structure and small size
Light weight thanks to its aluminium alloy
High in radiating efficiency
Important output diameter in relation to the space needed for the gear unit
Rust proof paint
Good static irreversibility for reduction ratio higher than 25

Fields of application:

Machine tools: press, press brake, trimmer, cutting
Conveyor, bottling, food industry, pharmaceutical, textile, paper...

*Output hollow shaft Ø25mm

Simple or double output shaft

ReferencesTypeDiameterLengthPlan

TNRV50_ARBSSimpleØ 25 mm153 mm

TNRV50_ARBDDoubleØ 25 mm199 mm

Simple output flange

TNRV50_FA
Gear unit output flange for coupling on the machine (FA type)

TNRV50_FBGear unit output flange for coupling on the machine (FB type)

TNRV50_FCGear unit output flange for coupling on the machine (FC type)

TNRV50_FDGear unit output flange for coupling on the machine (FD type)

Protective cover

TNRV50_PCOVEREnables to close the hole of the gear unit shaft (moving part)

Antirotation arm

TNRV50_ARMEnables to set the gear unit on the machine casing. For example for conveyors.

Motor adaptation

TNRV50_63B5Enables to mount a motor size 63 flange B5 on the gear unit

TNRV50_71B5Enables to mount a motor size 71 flange B5 on the gear unit

TNRV50_80B5Enables to mount a motor size 80 flange B5 on the gear unit

TNRV50_63B14Enables to mount a motor size 63 flange B14 on the gear unit

TNRV50_71B14Enables to mount a motor size 71 flange B14 on the gear unit

TNRV50_80B14Enables to mount a motor size 80 flange B14 on the gear unit

TNRV50_BU11Reduction from Ø11 to Ø9 for mounting the motor

TNRV50_BU14Reduction from Ø14 to Ø11 for mounting the motor

TNRV50_BU19Reduction from Ø19 to Ø14 for mounting the motor

Documentation

Dimensions
General documentation
Output shaft documentation
Assembly and maintenance

Softwares & 3D

Gear unit: TNRV50
Motor: 2 poles B14
Motor: 4 poles B14
Motor: 2 poles B5
Motor: 4 poles B5
