Compact speed adjustable motor 90 Watt 220 VAC Type 5
Compact speed adjustable motors low power MZD serie are composed of a DC motor and a high precision planetary reduction gearbox.
Technical characteristics:
- Voltage: 220 VAC
- Power: 90W
- Switch in the direction of rotation
Advantages:
-
- Low noise
- Modular
- High efficiency
- Light
Reference
Reference gear motor
Output nom.
speed RPM
speed RPM
Output torque
max N.m
max N.m
Ratio
MZD_5M4_090_U007LF
5GU200K
7.5 (0.45 to 6)
20
1:200
MZD_5M4_090_U010LF
5GU150K
10 (0.6 to 8)
20
1:150
MZD_5M4_090_U015LF
5GU100K
15 (0.9 to 12)
20
1:100
MZD_5M4_090_U020LF
5GU75K
20 (1.2 to 16)
20
1.75
MZD_5M4_090_U020LF
5GU50K
30 (1.8 to 24)
20
1:50
MZD_5M4_090_U050LF
5GU30K
50 (3 to 40)
13.6
1:30
MZD_5M4_090_U060LF
5GU25K
60 (3.6 to 48)
11.6
1:25
MZD_5M4_090_U100LF
5GU15K
100 (7.2 to 96)
7.70
1:15
MZD_5M4_090_U120LF
5GU12K5
120 (10 to 115)
6.40
1:12.5
MZD_5M4_090_U150LF
5GU10K
150 (15 to 140)
5.31
1:10
MZD_5M4_090_U300LF
5GU5K
300 (28 to 280)
2.80
1:5
MZD_5M4_090_U500LF
5GU3K
500 (45 to 470)
1.80
1:3
