Compact gear motor ZD T5 GU KB, 90x90 220Vac
Compact range T5GU KB, 220V 90W Output speed =7 RPM
close
Delivery throughout Europe
Secure payment
English speaker +33535565788
Compact gear motor 90 Watt 220 VAC Type 5
Compact gear motors low power MZD serie are composed of a DC motor and of a planetary reduction gear of high precision.
Technical characteristics:
- Voltage: 220 VAC
- Power: 90W
- Reversal in the direction of rotation
Advantages:
-
- Low noise
- Modular
- High efficiency
- Light
Reference
Reference gear unit
Output speed
nom. RPM
nom. RPM
Output torque
max N.m
max N.m
Ratio
MZD_5M4_090_U007LFB
5GU200KB
7.5 (0.45 to 6)
20
1:200
MZD_5M4_090_U010LFB
5GU150KB
10 (0.6 to 8)
20
1:150
MZD_5M4_090_U015LFB
5GU100KB
15 (0.9 to 12)
20
1:100
MZD_5M4_090_U020LFB
5GU75KB
20 (1.2 to 16)
20
1.75
MZD_5M4_090_U020LFB
5GU50KB
30 (1.8 to 24)
20
1:50
MZD_5M4_090_U050LFB
5GU30KB
50 (3 to 40)
13.6
1:30
MZD_5M4_090_U060LFB
5GU25KB
60 (3.6 to 48)
11.6
1:25
MZD_5M4_090_U100LFB
5GU15KB
100 (7.2 to 96)
7.70
1:15
MZD_5M4_090_U120LFB
5GU12K5B
120 (10 to 115)
6.40
1:12.5
MZD_5M4_090_U150LFB
5GU10KB
150 (15 to 140)
5.31
1:10
MZD_5M4_090_U300LFB
5GU5KB
300 (28 to 280)
2.80
1:5
MZD_5M4_090_U500LFB
5GU3KB
500 (45 to 470)
1.80
1:3
Articles related
5US590W
ZD speed adjustable motor
90W
5M55GU10XK
Decimal gearhead
Ratio 1:10
ZD5M5
Motor support
Mounting brackets for motor MZD 5
Certificates
CE Certificate
Documentation MZD_5M4_090_UXXLFB
Technical datasheet MZD_5M4_090_UXXLFB (FR) Technical datasheet MZD_5M4_090_UXXLFB (EN-DE)
Documentation MZD Size 5 (90x90)
Technical datasheet MZD T5 (FR) General specification compact gear motor MZD (EN)
