Power from 0.40 to 1.5kW
2-year warranty
It offers a triple advantage for managing an induction motor:
- The variable-frequency drive enables to transform 220V single-phase into 220V 3-phase, and thus to use a 220V/380V 3-phase motor (delta connection) on a standard outlet.
- The variable-frequency drive also enables to vary the supply voltage frequency (50Hz), and thus to vary the electric induction motor base speed (button on the front).
- The variable-frequency drive manages the motor start and stop phases, thus avoiding power peaks when the motor starts.
Visit our application possibilities: lathe equipment, milling machine, machine tool, wood machine, compressor, car lift, tire machine, conveyor, mixer...
Main functions:
- Variable frequency from 0 to 400 Hz by 0.1 Hz. Potentiometer included.
- 5 control inputs (AV/AR/Multi-speed...), 2 inputs 0/10V or 4-20 mA
- 2 TOR outputs (1 relay, 1 transistor), 1 analogue output.
- Braking with continuous power injection.
- PID loop
* The warranty only applies if the inverter is used in an IP55 electrical cabinet.
