Variable frequency drive Jaguar VXR

High industrial quality 5-year warranty
Power from 4 to 15 KW

Power kW

Reference VXR9A-4

Pre-order

€488.65 -5%
€464.22 Excl. tax

Inverter Vector Control

3Ø, 400V/50~60Hz, 4~15kW (5.5~20HP)

Filter CEM optional integrated
V/F or Control Vector
Starting torque >300% between 1-3Hz , 200% as of 0.5 Hz Stability at low speed in improved open loop
Control integrated by a mechanical brake
Brake transistor integrated and DC injection

3*400V:
Optional filter on request

Warranty: 5 years*

* Warranty only applies if the inverter is used in an IP55 electrical cabinet.

Reference

Power

Voltage

VXR9A-4

4 kW

3*400V

VXR13A-4

5.5 kW

13A

3*400V

VXR18A-4

7.5 kW

18A

3*400V

VXR24A-4

11 kW

24A

3*400V

VXR30A-4

15 kW

30A

3*400V

Documentation

documentation technic-achat Manual

Online support

aide en ligne Technic-Achat Different control modes for inverters
Braking and resistance on inverters
How to install an inverter on a woodworking machine?
How to protect your inverter?
Lathe tutorial
How to control an inverter in a multi-speed way?
How to choose a single/3-phase inverter?
aide en ligne Technic-Achat How to connect a remote control on an inverter?

Videos

Power kW

4 kW 5.5 kW 7.5 kW 11 kW 15 kW

Combinations	Power kW	Reference	Stock	Price	Add to cart
Power kW : 4 kW Reference : VXR9A-4 Stock : 0	4 kW	VXR9A-4	Available later	€488.65 Tax excl. €464.22 Tax excl. - 5%	€488.65 Tax excl. €464.22 Tax excl. (- 5%)
Power kW : 5.5 kW Reference : VXR13A-4 Stock : 0	5.5 kW	VXR13A-4	Available later	€701.85 Tax excl. €666.76 Tax excl. - 5%	€701.85 Tax excl. €666.76 Tax excl. (- 5%)
Power kW : 7.5 kW Reference : VXR18A-4 Stock : 1	7.5 kW	VXR18A-4	Available now Stock : 1	€783.21 Tax excl. €744.05 Tax excl. - 5%	€783.21 Tax excl. €744.05 Tax excl. (- 5%)
Power kW : 11 kW Reference : VXR24A-4 Stock : 0	11 kW	VXR24A-4	Available later	€1,201.49 Tax excl. €1,141.42 Tax excl. - 5%	€1,201.49 Tax excl. €1,141.42 Tax excl. (- 5%)
Power kW : 15 kW Reference : VXR30A-4 Stock : 0	15 kW	VXR30A-4	Available later	€1,442.61 Tax excl. €1,370.48 Tax excl. - 5%	€1,442.61 Tax excl. €1,370.48 Tax excl. (- 5%)
